Quality down to the finest detail.

Guides left, guides right. Even where others only pretend to do so. With spherical bushings on both sides to offer a double layer of protection in terms of keeping the carriage precisely on course across extra-large columns. Double-sealed for an extremely long service life, always exact and with zero play.

Twin-column guide with two bearings for unique precision
Dual-line laser for an accurate indication of the cutting line
Fine adjustment of the saw blade angle accurate to the millimetre from the front of the machine
Special cutting position for cutting depths up to 120 mm
FastFix saw blade changing for adaptation to the working material
Twin-column guide for accurate cuts
Precision angle transfer via bevel and dual-line laser
Compact, lightweight design for convenient transportation
Safety brake

Achieve ideal results more quickly:

Perfect seating from the very first cut thanks to exact marking of the cutting width via dual-line lasers and precision adjustment for angled cuts accurate to the millimetre

Convenient and safe:

Does not take up much space and never gets in the way, thanks to its compact design with no protruding guide rods

Innovative down to the finest detail:

No need to change saw blades and no set-up time thanks to the extra mitre position for expanding from a cutting depth of 88 mm to up to a maximum cutting depth of 120 mm

Usage

Main applications

Trimming skirting boards and cornices up to 120 mm in height – no calculations
Cutting boards and panels up to 305 x 88 mm
Trimming crown mouldings up to 168 mm in their original wall position
Trimming square timber and beams up to 88 mm thick

Technical Data

Power consumption: 1 600 W

Idle engine speed: 1 400 - 3 400 min⁻¹

Saw blade diameter: 260.00 mm

Cutting depth 90°/90°: 305 x 88 mm

Cutting depth at 45°/90°: 215 x 88 mm

Special cutting depth 90°/90°: 60 x 120 mm

Crown moulding diagonal cut 45°/90°: 168.00 mm

Inclination angle: 47/47 °

Mitre angle: 50/60 °

Dimensions (W x D x H): 713 x 500 x 470 mm

Cable length: 3.50 m

Product weight: 23.10 kg

Dust extraction connection diameter: 27/36 mm

Special cut. depth 45°/90° (left): 40 x 120 mm

Special cutting depth 45°/90° (right): 20 x 120 mm

Cutting depth 50°/90° (left): 196 x 88 mm

Cutting depth 60°/90° (right): 152 x 88 mm

Cutting depth 45°/45° (left): 215 x 55 mm

Cutting depth 45°/45° (right): 215 x 35 mm

Crown moulding diagonal cut at 90°/90°: 168.00 mm

Work height: 900.00 mm

Drive type: Mains
